Bioplay temperature monitoring service
From the customer's perspective, considering speed, accuracy, safety, convenience, and economics
This is a monitoring service provided.
INNOVATIVE BIO/PHARMA
COLD CHAIN TRANSPORTATION SERVICE
Bio Perfect Solution.
.png)
PRODUCT ADVANTAGE
- Temperature tracking possible using real-time LTE communication network (automatic transmission to cloud server)
- RFID Auto Pairing technology automatically matches transport containers, enabling an easy transport management system.
- Lasts up to 8 months on a single battery using low-power technology (duration may vary depending on communication interval settings)
- Efficiency of maintenance with Probe Sensor Attach/Detach technology
- The user can directly select the measurement temperature (6 modes), measurement interval (1~15 minutes), and communication transmission interval (1~24Hr).
- REC. Transport time can be identified through timer
- Locking Button function
- Intuitive identification of temperature maintenance and departure
- ISO 17025 Calibration Certified
- KC Radio Certification Certified
PRODUCT SPECIFICATION
- Model Name: CUBE VIEW-01
-Model No. : BP – DL - CUBE VIEW - 01
- Size : 68 X 108 X 20 (mm)
- Weight (Including Battery & Probe) : About 130g
- Measurement Range: -30 ~+70℃
- Temperature Accuracy: ±0.48℃
- Communication: LTE Cat. M1
- Battery: Lithium Ion Battery
- Calibration: ISO 17025 Certified
INNOVATION
CUBE VIEW is used to secure temperature data safely and accurately in bio/pharmaceutical cold chain transportation.
It was developed as a wireless communication type based on LTE-CAT.M1 and is equipped with IOT MATCHING FAIRING technology and
FIXEDWe implement advanced HIGH TECHNOLOGY with ATTACHABLE PROBE technology.
CUBE VIEW
CUBE CLOUD SERVICE
Using the IOT function of Bioplay Co., Ltd.'s transportation container and DATA LOGGER,
Built by us
The best BIO COLD CHAIN MONITORING with CLOUD SERVER
SERVICE is provided free of charge.
TEMPERATURE MONITORINGSYSTEM
VALIDATION
MONITORING
TRANSPORTATION
PACKAGING
PHARMACEUTICAL
SUPPLY CHAIN MIDDLE/LAST MILE
TRANSPORTATION SERVICE
Bioplay Co., Ltd. BIO/PHARMA COLD CHProvided by AIN HARDWARE
DASH BOARD
- Check contract details, packaging, and data logger operation status at a glance
- Via Information Summary
Check data information for each item
- Direct data download available
- Packaging Fairing can be checked
- Data Logger Battery information can be checked
DASH BOARD
- Check contract details, packaging, and data logger operation status at a glance
- Via Information Summary
Check data information for each item
- Direct data download available
- Packaging Fairing can be checked
- Data Logger Battery information can be checked
DASH BOARD
- Check contract details, packaging, and data logger operation status at a glance
- Via Information Summary
Check data information for each item
- Direct data download available
- Packaging Fairing can be checked
- Data Logger Battery information can be checked
DASH BOARD
- Check contract details, packaging, and data logger operation status at a glance
- Via Information Summary
Check data information for each item
- Direct data download available
- Packaging Fairing can be checked
- Data Logger Battery information can be checked
DASH BOARD
- Check contract details, packaging, and data logger operation status at a glance
- Via Information Summary
Check data information for each item
- Direct data download available
- Packaging Fairing can be checked
- Data Logger Battery information can be checked
DASH BOARD
- Check contract details, packaging, and data logger operation status at a glance
- Via Information Summary
Check data information for each item
- Direct data download available
- Packaging Fairing can be checked
- Data Logger Battery information can be checked
3D design/CFD flow analysis facilities and manpower available
What is Validation?
It is a technology and process that must be essential in the bio field as it is the task of proving that all procedures, processes, equipment, instruments, activities, systems, etc. actually lead to the expected results.
Provided by Bioplay Co., Ltd. Bio/Pharma Validation System
PACKAGING VALIDATION
- Temperature verification test in compliance with international regulations WHO, ISTA
▷ WHO (World Health Organization): World Health Organization
▷ ISTA (International Safe Transit Association): International Safe Transit Association
- Providing various validation transportation solutions for vaccines, specimens, human tissues, etc.
- Qualification Protocol & Report Documentation provided
- Various actual processes can be performed using certified test chambers, measuring equipment, etc.
Reliability system verified by case
TCV VALIDATION
CSV (Computer System Validation): Complies with computer system standards and specifications
Document operation, implementation, management, etc.
A system that secures data integrity and reliability
- Temperature verification test in compliance with international regulations WHO, ISTA
▷ WHO (World Health Organization): World Health Organization
▷ ISTA (International Safe Transit Association): International Safe Transit Association
- Ensure data integrity and reliability through our temperature monitoring system (TMS)
▷integrity(Integrity): All data is
Degree to how complete, consistent, and accurate something is.
- Securing reliability through IQ, OQ, and PQ qualification verification tests
CSV VALIDATION
TCV (Temperature Controlled Vehicle) Temperature controlled vehicle
- Temperature verification test in compliance with international regulations WHO, ISTA
▷ WHO (World Health Organization): World Health Organization
▷ ISTA (International Safe Transit Association): International Safe Transit Association
-Provides a total temperature solution from packaging to transportation and completion of delivery.
- Qualification Protocol & Report Documentation provided
- Securing reliability through IQ, OQ, and PQ qualification verification tests
CUBE
VALIDATION
SERVICE
MANAGEMENT PHILOSOPHY
In an era where various diseases and viruses coexist,
For biopharmaceutical transportation
Bioplay Co., Ltd. is trying various things.
CUBE
EPP SERIES
CUBE-P17
CUBE EPP is a reusable container optimized for domestic and international bio/pharmaceutical cold chain transportation and can be used for up to 120 hours.
We promise to transport medicines safely by maintaining the target temperature.
PRODUCT ADVANTAGE
- Functionality: Excellent cold insulation / durable structural design
- Specialty: special insulation interpolation technology
- Customized: Preemptive caloric analysis/can select container by target time (ISTA 7D 12 ~ 120 hrs)
- Reliability: Obtained domestic and international certification (KCL performance certification / ISTA performance certification)
- Convenience: Implementation of IoT technology and data logger linkage function
PRODUCT ADVANTAGE
- Maintain optimal temperature by using a special insulating coating film
- Various temperature ranges from -60℃ to 0~30℃ refrigerated/room temperature
- Waterproof outer shell and detachable inner shell for easy cleaning and maintenance
- Various internal capacities can be set through customization (10~50 liters)
- Equipped with data logger linkage function using IOT technology
PRODUCT ADVANTAGE
- Apply special structure of INCASE, realize customized temperature in winter
- Special SENSOR HOLE/waterproof zipper applied to minimize HEAT BRIDGE
- Improved economic efficiency and temperature performance using refrigerant (SAP)
- Various internal capacities can be set through customization (5~20 liters)
- Equipped with data logger linkage function using IOT technology
CUBE BAG
SERIES
CUBE BAG is optimized for domestic short-distance bio/pharmaceutical cold chain transportation.
As a reusable bag, up to 30 hours
We promise to transport medicines safely by maintaining the target temperature.
CUBE U-BAG
CUBE BP-BAG
CUBE U-BAG VALIDATION REPORT
CUBE BP-BAG VALIDATION REPORT
CUBE-EPP SPECIFICATION
CUBE-EPP VALIDATION REPORT
INNOVATIVE BIO/PHARMA
COLD CHAIN TRANSPORTATION SERVICE
BioPlay Co., Ltd.’s professional bio cold chain hardware operation technology and
Through transportation solution technology utilizing the routing system of GogoX Korea Co., Ltd.
We promise to provide next-generation bio/pharmaceutical logistics/transportation services.
